Modern and futuristic, with the attractive specifications and perfect balance, the Race Sport (RS) Edition is the evolution of the most popular PRO series motherboard. Its unique path takes aim at mainstream DIYers that drives an undeniable performance and trustable computing experience without a pricey upgrade. RaceSport edition, your all-rounder motherboard that fulfills every task and light-loading gaming – with style and speed!

FEATURES

• Supports 14^th, 13^th & 12^th Gen Intel^® Core™ Processors (LGA1700)
• 7+1+1 Power Phase, Dr.MOS for VCore+GT
• 4x DDR5 DIMMs - Supports Dual Channel, up to 7200+ (OC)
• 1x PCIe 5.0 x16, 1x PCIe 3.0 x16
• Graphics Output Options: 1 HDMI, 1 DisplayPort
• Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
• 4x SATA3, 3 Hyper M.2 (PCIe Gen4x4)
• 2x USB 3.2 Gen1 Type-C (1 Rear, 1 Front), 5 USB 3.2 Gen1 Type-A (3 Rear, 2 Front), 6 USB 2.0 (2 Rear, 4 Front)
• Dragon 2.5G LAN
• Killer 802.11axe WiFi 6E + Bluetooth
• Supports ASRock Auto Driver Installer

SPECIFICATIONS

• CPU
  - Supports 14^th, 13^th & 12^th Gen Intel^® Core™ Processors (LGA1700)
  - Supports Intel Hybrid Technology
  - Supports Intel Turbo Boost Max 3.0 Technology
  - Supports Intel Thermal Velocity Boost (TVB)
  - Supports Intel Adaptive Boost Technology (ABT)
• Chipset - Intel B760
• Memory
  - Dual Channel DDR5 Memory Technology
  - 4 x DDR5 DIMM Slots
  - Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)*
  - Max. capacity of system memory: 256GB
  - Supports Intel Extreme Memory Profile (XMP) 3.0
  *1DPC 1R Up to 7200+ MHz (OC), 4800 MHz, 1DPC 2R Up to 6000+ MHz (OC), 4400 MHz, 2DPC 1R Up to 5600+ MHz (OC), 4000 MHz, 2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively.
• BIOS - 128Mb AMI UEFI Legal BIOS with GUI support
• Graphics
  - Intel Xe Graphics Architecture (Gen 12)
  - 1x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz
  - 1x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
  * Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.
• Audio - 7.1 CH HD Nahimic Audio (Realtek ALC897 Audio Codec)
• LAN
  - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
  - Dragon RTL8125BG
  - Supports Dragon 2.5G LAN Software
  - Smart Auto Adjust Bandwidth Control
  - Visual User Friendly UI
  - Visual Network Usage Statistics
  - Optimized Default Setting for Game, Browser, and Streaming Modes
  - User Customized Priority Control
• Wireless LAN
  - 802.11axe Wi-Fi 6E Module
  - Supports IEEE 802.11a/b/g/n/ac/ax/axe
  - Supports Dual-Band 2x2 160MHz with extended 6GHz band* support
  - 2 antennas to support 2 (Transmit) x2 (Receive) diversity technology
  - Supports Bluetooth 5.3 + High speed class II
  - Supports MU-MIMO
  - Supports Killer LAN Software
  *The 6GHz band of Wi-Fi 6E module is supported by Microsoft Windows^® 11 only. The availability of the 6GHz band will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows^® Update and software updates once available. A 6GHz compatible router is required for 6E functionality.
• Expansion Slots
  CPU:
  - 1x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
  Chipset:
  - 1x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode*
  - 1x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT)
  - Supports AMD CrossFire
  * Supports NVMe SSD as boot disks
• Storage
  CPU:
  - 1x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
  Chipset:
  - 1x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 1x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
  - 4x SATA3 6.0 Gb/s Connectors
  * Supports Intel Volume Management Device (VMD)
  Supports NVMe SSD as boot disks
• RAID - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
• USB
  Chipset:
  - 2x USB 3.2 Gen1 Type-C (1 Rear, 1 Front)
  - 5x USB 3.2 Gen1 Type-A (3 Rear, 2 Front)
  - 6x USB 2.0 (2 Rear, 4 Front)
  * All USB ports support ESD Protection
• Form Factor: Micro ATX (24.4 x 24.4 cm)
• OS Support: Microsoft Windows 10 64-bit / 11 64-bit
• Warranty: 36 Months
